Linn Kolektor Pre Amplifier

The Kolektor is a Linn modular, expandable and supportable product that offers low noise and high quality audio performance and satisfies international safety and EMC standards. The new ten input Linn Kolektor is a versatile high fidelity preamplifier designed to manage and control the ever increasing number of sound source formats with an easy to use, high quality, simple, flexible control system that can also accept an optional RS232 interface card.
The Kolektor combines high precision solid state switching with electronic gain control and has surface mounted components to maximise signal integrity and minimise noise.
On the Kolektor the low noise phono stage is precision equalised, fully integrated and electronically switched to avoid any mechanical connections in the sensitive phono signal path. A separate headphone amplifier is used to drive high quality headphones without compromising signal quality in the main audio path.
The Kolektor has more facilities than a conventional Linn preamplifier. The tone controls fitted to the Kolektor are also very different from normal bass and treble controls. To avoid adding distortion the bass control has maximum effect at 40 Hz and the treble at 20 kHz so that they only operate at the boundaries of the audible audio band. This facility enables the subtle refinements to a playback system that discerning listeners need to adjust the sound of passive compact loudspeakers and allow a system to be flexibly located within any listening room and to suit every type of music.

Audio Input Impedance:
Input 1: 47 kΩ in parallel with 68 pF; Inputs 2 to 10: 50 kΩ
Maximum Input Level: 2.5 V rms
Nominal Input Levels:
Line inputs: 2 Vrms; Phono (MM) input: 2.5 mVrms
Output Impedance:
Line outputs: 300 Ω; Tape output: 100 Ω
Gain:
Line Inputs: 10 dB maximum
Phono input: 45 dB maximum @ 1 kHz
Tape output: 0 dB from line inputs; 36 dB from phono input @ 1 kHz
Gain Control Range: 60 dB in 1 dB steps
Response Adjustments:
Bass: ± 10 dB at 40 Hz; Treble: ± 10 dB at 20 kHz
Mains Supply Fuses:
100 - 115 Vac T800 mA 220 - 240 Vac T400 mA
Power Consumption: 8 W maximum
Dimensions: 320 (W) x 325 (D) x 80 (H) mm
Weight: 4.0 kg
