Arcam AVR20 AV Amplifier

Here we have a high quality Audio/Visual amplifier from British based company Arcam. Our AVR20 comes in very good fully working condition with a couple of cosmetic marks – please see photographs. It will be supplied professionally packaged along with remote control, manual, mains cable, USB cable, DAB/FM aerial; 3 x Wi-Fi/Bluetooth antennas and our usual three month warranty.
Arcam Audio Say….
The design of the HDA range draws upon all of Arcam’s experience as one of the UK’s most respected audio companies, to produce Arcam’s best performing range of audio products yet – using the best quality components and engineering practices, the HDA range is designed and built to give you years of listening enjoyment.
The AVR20 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 16-channel surround solution and featuring all the latest CODECs from Dolby, DTS, Auro-3D and IMAX Enhanced, the AVR20 exemplifies sound quality and engineering excellence.
The AVR20 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 16-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple AirPlay2 or Google Chromecast.
Features:
Dolby Atmos, IMAX Enhanced, Auro-3D & DTS:X 9.1.6 decoding
4K (UHD) HDMI2.0b with HDCP2.2
7 HDMI inputs, 3 HDMI outputs, eARC compatible
Dirac Live® for Arcam room correction
ESS 9026PRO audiophile DAC
Class AB power amplification – Uses toroidal transformer
Wi-Fi / Ethernet, RS232 and IR control
Google Cast/UPnP capability for streaming audio
Roon Ready Certified
MQA supported
Bluetooth
Free MusicLife iOS UPnP and control app
Specifications:
Power Output into 8 Ω/4 Ω
2 Channels Driven, 20 Hz – 20 kHz, < 0.02 % THD: 110 W/175 W
2 Channels Driven, 1 kHz, 0.2 % THD: 125 W/190 W
7 Channels Driven, 1 kHz, 0.2 % THD: 90 W/110 W
Residual Noise & Hum (A-wtd): < 0.15 mV
Stereo Line Inputs
Maximum Input: 4.5 V rms
Nominal Sensitivity: 1 V, 2 V, 4 V (user adjustable)
Input Impedance: 47 kΩ
Signal/Noise Ratio (A-wtd ref 100 W) normal/stereo direct: 100 dB/110 dB
Frequency Response: 20 Hz – 20 kHz ± 0.2 dB
Preamplifier Outputs
Nominal Output Level: 1 V RMS (max. 5 V RMS)
Output Impedance: 560 Ω
THD+N (20 Hz – 20 kHz): – 100 dB
Headphone Output
Maximum Output Level Into 32 Ω: 5 Vrms
Output Impedance: < 100 Ω
General
Mains Voltage: 110 – 120 V or 220 – 240 V, 50 – 60 Hz
Power Consumption: 1.5 kW (Maximum); 100W (Idle, Typical); < 0.5 W (Standby)
Dimensions: 433 (W) x 425 (D) x 171 (H) mm
Weight: 16.6 kg
